Garmin GPSMAP 1223xsv

Garmin GPSMAP 1223xsv - GET A SHARPER VIEW FROM YOUR CONNECTED HELM
With 50% more touchscreen pixels and nearly double the processing power of previous-generation 12" GPSMAP devices, this crisp chartplotter/sonar combo with high-resolution IPS display integrates seamlessly into your Garmin marine system.

GPSMAP 1223xsv is one of the best combo units on the market for boating and sailing. The display is exceptionally bright and sharp, the software is Garmin's best, and the versatile features help you move on the water efficiently and safely. We recommend the GT56 side-scan transducer for this model to get some of the best side-scan images on the market with excellent resolution.

Garmin GT56UHD-TM transducer details:

• ULTRA HIGH-DEFINITION CLEARVÜ SCANNING SONAR
  See structure and fish below your boat clearly and at greater depths than with other high-frequency scanning sonars. Its downward-facing element puts more power on targets.
• ULTRA HIGH-DEFINITION SIDEVÜ SCANNING SONAR
  See all structure and fish off to the sides of your boat at once and with outstanding clarity. SideVü sonar now has 20% greater range at 1,000 kHz, so you can see even farther.
• HIGH WIDE CHIRP TRADITIONAL SONAR
  The sonar separates and defines targets below your boat with remarkable clarity down to 244 m (800 ft).
• MULTIPLE SCANNING SONAR FREQUENCIES
  Use the frequency best suited to the waters you fish. This transducer delivers 455, 800 and 1,000 kHz, so it performs excellently at all depths.
• VIVID COLORS
  Bright and clear scanning sonar colors make it easier to distinguish targets and structure.

You can connect the Garmin LiveScope System transducer package to the display via the Ethernet network to get live sonar.

Garmin GPSMAP 1223xsv features:

• Integrates easily with a wide range of engines.
• Connect to compatible third-party devices with OneHelm digital switching.
• Expand your marine system easily with premium networking.
• Compatible with Garmin's best navigation charts.
• Clear laylines and other display data give extra confidence when sailing.
• Manage your boating from almost anywhere.

ULTRA HIGH-DEFINITION SCANNING SONAR
Get built-in Ultra High-Definition SideVü and ClearVü scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP 1223xsv also supports 1 kW CHIRP traditional sonar capabilities.

PANOPTIX SONAR SUPPORT
Pair with Panoptix or Panoptix LiveScope easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.

FASTER, SHARPER, SMARTER
With its added processing power and new slimline design featuring edge-to-edge glass and a smaller unit footprint, it's easy to retrofit this 12" plotter in a wider range of dash configurations.

IMPROVED DISPLAY OPTICS
New higher-resolution 12" IPS displays offer improved sunlight readability and visibility from any angle, with 50% more pixels than previous-generation 12" GPSMAP devices.

GARMIN SAILASSIST SAILING FEATURES
View laylines, race start line guidance, an enhanced wind rose, heading and course over ground lines, true wind data fields, a tide/current/time slider bar, wind angle, current set and drift, and wind speed.

OPTIONAL BLUECHART G3 VISION CHARTS
These optional charts offer the best of Garmin and Navionics data, Auto Guidance3 technology and other premium navigation features.

OPTIONAL RADAR BUNDLE
To help you avoid weather and traffic on the water, the compact 4 kW GMR 18 HD+ dome radar is available as a bundled option with your GPSMAP chartplotter/sonar package.

GARMIN MARINE NETWORK
If you have multiple compatible Garmin devices on your boat, you can share information - such as maps, user data, radar and IP camera video - among them.

NMEA 2000 AND NMEA 0183 NETWORKS
Connect to compatible autopilots, digital switching, weather, Fusion-Link audio system, media, VHF, AIS and more from one screen.

ACTIVECAPTAIN APP
Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, smart notifications, software updates, Garmin Helm digital switching, Garmin Quickdraw Community data and more4.

INTEGRATED ANT TECHNOLOGY
Connect with some of your favorite devices, such as quatix marine watches, gWind Wireless 2 transducers, GNX Wind marine instruments and wireless remote controls.

J1939 CONNECTIVITY
Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.

ONEHELM FEATURE
This exclusive feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus digital switching, on one screen.

PANOPTIX SONAR SUPPORT WITH FRONTVÜ
Pair with Panoptix or Panoptix LiveScope easy-to-interpret live sonar (transducer sold separately) featuring FrontVü scanning sonar, so you can see and avoid underwater obstacles in real time at distances up to 91 m.

Garmin GPSMAP 1223 in the box:

• GPSMAP 1223 chartplotter
• Preloaded microSD card
• Power cable
• NMEA 2000 T-connector
• NMEA 2000 drop cable (2 m)
• Bail mount kit and knobs
• Flush mount kit and gasket
• Protective cover
• Snap-on trim pieces
• Documentation
