Vector Optics HEIM ES X-Nano XPD Wi-Fi is an unusually compact thermal sight designed to bring thermal observation into a package closer in size to a miniature red dot than a conventional thermal optic. At 51 x 43 x 46 mm and 123 g, it adds relatively little bulk to a compatible setup. The mounting interface is VOD, compatible with the Aimpoint ACRO footprint, which makes compatibility with bases and adapters easier to assess before installation. The X-Nano is intended primarily for rapid thermal detection at short and medium distances: its wide view, small dimensions and fast image refresh are more central to the design than high optical magnification.
Thermal imaging is based on a sensor with a resolution of 256 x 192 pixels, 12 µm pixel pitch and 50 Hz frame rate. A 50 Hz refresh helps keep motion fluid while scanning or following a moving heat source. The 19 mm objective, 0.5x base magnification and 13.5 x 10.1 degrees field of view favour situational awareness and rapid searching. Viewing modes are 0.5x and 1x, and the focus range is 5 m to infinity. NETD is up to 40 mK; this figure describes the sensor's ability to distinguish small temperature differences. The manufacturer states a detection range of up to 600 m and an identification range of up to 150 m. Actual performance depends strongly on target size, temperature contrast, weather and terrain, so the model is best understood as compact thermal detection with a broad view rather than a high-magnification long-range thermal scope.
The XPD Wi-Fi version adds wireless connectivity and app support. Through the built-in Wi-Fi link, the user can access real-time thermal viewing, settings control, photo capture and video recording, giving the small optic a larger alternative display and a convenient way to document observations. The unit itself has a 1.4-inch touchscreen and six thermal palettes: White Hot, Black Hot, Hot Iron, Rainbow, Iron Red and Cold Color. Hot Spot Tracking provides real-time detection and marking of the hottest area in the image. The sight also offers 10 reticle options in black, white, red, green and yellow. For field use, the manufacturer specifies 1000 G shock resistance and IP66 protection, with an operating range of -20...+60 °C. Power comes from a replaceable 16280 battery rated at 900 mAh, with a manufacturer-stated runtime of about 3.5 hours per battery. Charging is via USB-C, 5 V; the package includes 3 batteries and a dual-slot charger, so a charged battery can replace a depleted one in the field.
Vector Optics HEIM ES X-Nano XPD Wi-Fi - Features:
- Product type: compact thermal sight
- Model: VEOT-RSS08, HEIM ES X-Nano XPD Mini Thermal Sight Wi-Fi
- Thermal sensor resolution: 256 x 192 pixels
- Pixel pitch: 12 µm
- Frame rate: 50 Hz
- NETD: up to 40 mK
- Objective: 19 mm
- Base magnification: 0.5x
- Viewing modes: 0.5x and 1x
- Field of view: 13.5 x 10.1 degrees
- Focus range: 5 m to infinity
- Manufacturer-stated detection range: up to 600 m
- Manufacturer-stated identification range: up to 150 m
- Display: 1.4-inch touchscreen
- Thermal palettes: White Hot, Black Hot, Hot Iron, Rainbow, Iron Red and Cold Color
- Hot Spot Tracking: real-time detection and marking of the hottest area in the image
- Reticle options: 10 options
- Reticle colours: black, white, red, green and yellow
- Wi-Fi: built-in Wi-Fi and app support
- Smartphone functions: real-time thermal viewing, settings control, photo capture and video recording
- Mounting standard / footprint: VOD, compatible with the Aimpoint ACRO footprint
- Dimensions: 51 x 43 x 46 mm
- Weight: 123 g
- Shock resistance: 1000 G
- Ingress protection: IP66 according to the manufacturer
- Operating temperature: -20...+60 °C
- Battery: replaceable 16280 battery, 900 mAh
- Manufacturer-stated runtime: about 3.5 hours per battery
- Charging: USB-C, 5 V
- Batteries included: 3
- Battery charger: dual-slot charger
- Warranty: 2 years
Summary: Vector Optics HEIM ES X-Nano XPD Wi-Fi combines a very compact 123 g body with a resolution of 256 x 192 pixels, 12 µm pixel pitch, 50 Hz, a 19 mm objective and a wide 13.5 x 10.1-degree field of view. Hot Spot Tracking, Wi-Fi photo/video functions, an ACRO-compatible VOD interface and replaceable batteries make it especially relevant when a full-size thermal optic would add unnecessary weight and bulk.
Recommended use: Recommended for users who want a very small and light thermal optic for short- to medium-range detection and observation. The wide field of view and low base magnification favour finding heat sources quickly in darkness or poor visibility rather than high-magnification identification at long range. The Wi-Fi version is also useful when the image needs to be viewed on a larger phone display or observations recorded. For hunting or shooting use, verify secure mounting and zero as well as the local rules governing thermal sights.
