HIKMICRO NEOS NH25L

HIKMICRO NEOS NH25L is a compact thermal riflescope that combines a 320 × 240 pixel thermal sensor, thermal sensitivity below 18 mK, a fast 25 mm F1.0 lens, a 1000 m laser rangefinder, and integrated ballistic calculation. The NH25L offers the lightweight, traditional riflescope-like design of the NEOS series for users who want both thermal detection and measured distance directly through the scope.

The 320 × 240 pixel VOx thermal sensor provides more image information than the sensor in the base NE25 model. A 12 µm pixel pitch, 50 Hz frame rate, and NETD below 18 mK help produce detailed, smooth thermal imagery even when the temperature difference between the target and the environment is small.

The 25 mm F1.0 lens offers a stated detection range of up to 1200 metres. Base magnification is 3.5×, with a magnification range up to 24.5×. The 7.0 × 5.3 degree field of view corresponds to approximately 12.2 × 9.3 metres at 100 metres, allowing the device to both search for targets efficiently and examine them at higher magnification.

A key feature of the NH25L is the integrated 905 nm laser rangefinder. It measures distances from 10 metres up to 1000 metres with ±1 metre accuracy. Distance is displayed directly in the scope view without the need for a separate measuring device, which is particularly helpful for estimating distance in the dark.

The laser rangefinder is complemented by built-in ballistic calculation. When the required ballistic data is entered into the system, the scope can use the measured distance to calculate ballistic correction. This brings thermal detection, distance measurement, and ballistic data into one system.

HIKMICRO's Image Pro 3.0, Zoom Pro, Sync Pro, and HSIS Shutterless Image System process the image from the sensor to the display. Image Pro 3.0 helps reveal thermal image details, Zoom Pro supports digital magnification, Sync Pro reduces latency, and HSIS helps keep the image continuous without calibration interruptions caused by a conventional shutter.

The image is displayed on a large 0.49-inch 1920 × 1080 AMOLED display. A long 55 mm eye relief and -4...+4 dioptre adjustment make it easier to adapt the scope to the user. Six thermal image palettes offer options for different conditions and personal preferences.

The NH25L includes 64 GB of internal memory for video, photos, and audio recordings. Recoil-activated recording helps preserve events without needing to remember to start recording manually.

Power is supplied by an internal rechargeable battery and a replaceable 18650 battery. The manufacturer's stated operating time is up to 9 hours. The replaceable battery allows operating time to be extended quickly in the field with a spare battery.

The NH25L weighs only approximately 550 grams and uses a standard 30 mm main tube. IP67 protection, a wide operating temperature range of -30...+55 °C, and recoil resistance of up to 1000 g / 0.4 ms support use in demanding hunting conditions.

HIKMICRO NEOS NH25L - key features

• Thermal sensor: uncooled VOx, 320 × 240 px
• Pixel pitch: 12 µm
• NETD: <18 mK @ 25 °C, F1.0
• Frame rate: 50 Hz
• Lens: 25 mm F1.0
• Detection range: up to 1200 m
• Minimum focus distance: 3 m
• Magnification: 3.5?24.5×
• Field of view: 7.0° × 5.3° / 12.2 × 9.3 m @ 100 m
• Laser rangefinder: 10?1000 m
• LRF accuracy: ±1 m
• Ballistic calculation: yes
• Display: 0.49" AMOLED, 1920 × 1080 px
• Eye relief: 55 mm
• Internal memory: 64 GB
• Main tube: 30 mm
• Protection rating: IP67
• Operating temperature: -30...+55 °C
• Battery life: up to 9 h
• Weight: 550 g
• Dimensions: 345.6 × 86.1 × 75.8 mm

Other features

• Image processing: Image Pro 3.0, Zoom Pro, Sync Pro, and HSIS Shutterless Image System
• Image adjustments: brightness and contrast adjustment, plus Cold and Warm tones
• Thermal image modes: six colour palettes
• Recording: video, photo, and audio recording, plus recoil-activated recording
• Display functions: Picture-in-Picture and local album
• Zeroing: Freeze Zeroing and five zeroing profiles
• Connectivity: Wi-Fi hotspot and HIKMICRO Sight app support
• Power system: internal rechargeable battery and replaceable 18650 battery
• Charging: USB Type-C and QC3.0 fast charging
• Laser: Class 1 laser, wavelength 905 nm
• Click value: 1 cm / 100 m
• Recoil resistance: up to 1000 g / 0.4 ms
• Start-up time: approximately 1 second

Package contents

• HIKMICRO NEOS NH25L thermal riflescope
• Replaceable rechargeable battery
• Battery charger
• USB Type-C cable
• Lint-free cleaning cloth
• Quick start guide

Recommended use: The HIKMICRO NEOS NH25L is suitable for hunters who need accurate distance measurement and ballistic calculation in addition to a compact thermal riflescope. It specifically addresses the uncertainty of distance estimation in the dark and reduces the need to use a separate laser rangefinder. The 25 mm lens and relatively wide field of view make the NH25L a good option for wooded and varied terrain where observation distances change quickly.
