Garmin GPSMAP 1623xsv

Garmin GPSMAP 1623xsv - Embrace connectivity, clarity and control at the helm with the GPSMAP 16x3 chartplotter. This advanced MFD supports the same easy-to-use features from our GPSMAP x3 series but with a bigger 16” HD IPS touchscreen display. Anglers can enjoy options such as built-in support for the full line of LiveScope and Panoptix sonars, ClearVü and SideVü scanning sonars, and Garmin CHIRP traditional sonar (transducer required; sold separately). Once you find the fish, stay on them with Force® trolling motor support and integration. Enjoy simple navigation with support for Garmin Navionics+ charts with Auto Guidance+ technology1, and a one-year subscription that comes with daily updates, or upgrade to premium charts from Garmin Navionics Vision+ for high-resolution relief shading and more. Connect multiple chartplotters, radars, cameras and more with seamless vessel integration on the Garmin Marine Network. Sailors at the helm can enjoy premium sailing features, such as sailing polars, and see laylines, race start line guidance and more with Garmin SailAssist features.

Garmin GPSMAP 1623xsv Main Features:

• 16” DISPLAY: High-resolution 16” touchscreen, IPS display offers sunlight readability and visibility from any angle, even with polarised glasses.
• MAPS AND CHARTS: Support for mapping includes Garmin Navionics+ charts with built-in Auto Guidance+ technology1, and a one-year subscription that comes with daily updates or an upgrade to Garmin Navionics Vision+ cartography with premium features, such as high-resolution relief shading.
• DESIGN: Slim display borders and edge-to-edge glass make it easy to fit a wide range of helm configurations
• SONAR CAPABILITIES: Sonar models offer built-in Ultra High-Definition SideVü and ClearVü scanning sonars with high-contrast vivid colour palettes, which help distinguish fish from structure; supports optional Panoptix and LiveScope sonar devices as well as CHIRP traditional sonar (transducer required; sold separately).
• CUSTOMISABLE: OEMs can customise the home screen for a brand-tailored experience
• SAILING FEATURES: Built-in Garmin SailAssist features, including laylines, race start guidance, set and drift, wind data and more.
• DIGITAL INTEGRATIONS: J1939 and NMEA 2000® engine connectivity for easy integration with engines and our exclusive OneHelm feature for connecting to compatible third-party devices, such as EmpirBus digital switching
• NETWORKING: Easily build your marine system — from compatible sonar, autopilot, radars or cameras — by using NMEA 2000 and NMEA 0183 network connectivity and the Garmin Marine Network
• WI-FI® TECHNOLOGY: Use built-in Wi-Fi technology to pair with the free ActiveCaptain® app for access to OneChart , smart notifications, software updates and more (requires app on your compatible smartphone).
• ANT® TECHNOLOGY: Integrated ANT technology support for use with your compatible quatix® marine smartwatches, gWind Wireless 2 transducer, GNX Wind marine instrument and wireless remote controls
• BUILT-IN GPS: References 10 Hz GNSS (GPS, GLONASS and Galileo) for accurate positioning and smooth speed as well as COG data
• FORCE & FORCE KRAKEN TROLLING MOTOR CONTRO: Get support and integration for your Force® trolling motor (sold separately) to gain complete control while you fish

Garmin GPSMAP 1623xsv and 8416xsv Product Compared:

• Display size diagonal: GPSMAP 1623xsv & GPSMAP 8416xsv: 5.6" (39.7 cm)
• Display resolutio: GPSMAP 1623xsv & GPSMAP 8416xsv: 1920 x 1080 pixels
• Display type: GPSMAP 1623xsv & GPSMAP 8416xsv: FHD, IPS

• Mounting option: Flat and flush, bail with optional accessory

• Video input:
  GPSMAP 1623xsv: 1 (BNC composite)
  GPSMAP 8416xsv: 1 (BNC composite), 1 HDMI (HDCP compliant)
• Video output:
  GPSMAP 1623xsv: 1 HDMI
  GPSMAP 8416xsv: 1 HDMI
• Audio output:
  GPSMAP 1623xsv: No
  GPSMAP 8416xsv: Yes

• Traditional sonar:
  GPSMAP 1623xsv: Single channel CHIRP, 50/70/83/200kHz, L, M, H CHIRP (built-in xsv models only)
  GPSMAP 8416xsv: Dual channel CHIRP, 70/83/200 kHz, L, M, H CHIRP (built-in xsv models only)
• Transducer ports built-in:
  GPSMAP 1623xsv: Single port – 12-pin (xsv models only)
  GPSMAP 8416xsv: Dual ports – 8-pin and 12-pin (xsv models only)
• Panoptix and LiveScope sonar support: YES
• ClearVu and SideVu: GPSMAP 1623xsv & GPSMAP 8416xsv: 260/455/800/1000/1200 kHz (built-in xsv models only)

• GPS: GPSMAP 1623xsv & GPSMAP 8416xsv: 10Hz
• Memory cards: GPSMAP 1623xsv & GPSMAP 8416xsv: 2 MicroSD
• Network ports (RJ45): GPSMAP 1623xsv & GPSMAP 8416xsv: 2 port
• NMEA 2000 port: GPSMAP 1623xsv & GPSMAP 8416xsv: 1 port
• J1939 port: GPSMAP 1623xsv & GPSMAP 8416xsv: 1 port
• USB input: GPSMAP 1623xsv & GPSMAP 8416xsv: 1 input
• Quickdraw Contours: YES
• OneHelm connectivity: YES

Includes:

• Chartplotter, microSD preinstalled, power cable, NMEA 2000® T-connector, NMEA 2000 drop cable, flush mount kit with gasket, protective cover, trim piece snap covers, xsv models only: 8-pin transducer to 12-pin sounder adapter cable and documentat.
